Black Horse Model
Viper Jet MKII
1.88 m EDF sport jet with 120 mm fan
JetARFEDFElectricExperienced
The Viper Jet MKII is a sleek sport jet with a clean, scale-accurate outline and strong flying performance. Black Horse builds it entirely from balsa and plywood and covers it in polyester film for durability, lightness and easy repair, with a 1885 mm wingspan.
The high wing loading gives a fast, precise flight attitude for experienced and expert pilots. A Smart-lock quick-assembly system fits the wings and stabiliser without tools, and electric retracts with CNC full-metal suspension fork gear and controller box are included. Powered by a 120 mm EDF fan.
Highlights
- Smart-lock tool-free quick assembly of wings and stabiliser
- All balsa and plywood, covered in polyester film
- Electric retracts with CNC full-metal fork gear (included)
- Retract controller box (included)
- Removable canopy for easy battery changes; powered by 120 mm EDF
Specifications
| Wingspan | 1885 mm |
| Length | 1820 mm |
| Weight | 8900–9100 g |
| Wing area | 62.2 dm² |
| Wing loading | 143.1 g/dm² |
| Wing profile | NACA |
| Landing gear | Electric retract main gear with CNC full-metal fork, nose gear with oleo struts and controller box (incl.) |
| Covering | Polyester film |
What you need (not included)
| Radio | 8+ channels |
| Servos | 8 high-torque (33x17 mm) |
| Ducted fan (EDF) | 120 mm |
Electric conversion – guideline
| Motor | 120 mm EDF, brushless, 685 KV |
| Speed controller (ESC) | 160 A |
| Battery (LiPo) | 10–12S 6000 mAh |
Specifications according to the manufacturer. Motor, radio, servos and battery are not included unless otherwise stated.
