Product Info:
Futaba RS303MR - Command-type industrial servoCoreless motor and metal gear, TTL command system.
The TTL command servo was developed in response to customer requests for the RS305CR's shape and output to be used with the PWM method, just like radio-controlled servos. Because it can be controlled with conventional R/C servo PWM signals, it can be controlled with radio-controlled receivers and PWM servo control boards made by other manufacturers.
Specs:
- Torque: 6.5kg/cm
- Speed: 0.11s/60°
- Weight: 28g
- Dimensions: 35.8×19.5×25.0mm
- Power supply voltage: 4.8 to 7.4V
- Range of motion: 300°
- Communication format: TTL half-duplex communication/PWM method
- Please refer to the instruction manual for dimensions and mounting hole positions
