Palm-Sized. Seriously Capable.
Only 84x84x45mm. Compact enough to fit in your palm, yet engineered to perform like a much larger charger. Built for the bench, ready for the field.
65W Maximum Focus.
Up to 65W of charging power gets your batteries back in action sooner, with stable and efficient charging every time.
10A Faster by Far.
With up to 10A of charging current, every charge is more efficient—so you spend less time waiting and more time flying or racing.
Balanced. Down to Every Cell.
Working together, the main output and balance port continuously monitor and balance the voltage of every cell throughout the charging process, delivering safer, more stable charging while helping extend battery life.
Do More With One Charger! Multiple Chemistries Go.
With exceptional versatility, S65neo can charge a wide range of battery chemistries. This powerhouse can charge everything from LiPo and LiFe to Li-ion, LiHV, Pb, NiMH, and NiCd. Unlock the full potential of your battery arsenal with S65neo – versatility multiplied capability.
Discharging Multiplied by Balance Port
The built-in balance port works alongside the main output to boost discharge power to 10W, making battery maintenance faster and more efficient.
So Pro. So Digital.
From charging batteries to powering your equipment, S65neo does both. Adjustable 6–17V output and 0.5–9A current make it a capable DC power supply, complete with short-circuit, overload, and reverse-polarity protection.
Know the Resistance. Know Your Battery.
Instantly measure internal resistance to better understand battery health and discharge performance, so every charge starts with confidence.
Advanced Rectifier Circuit. Efficiency, Elevated.
High-efficiency power conversion and precision MCU control work together to reduce power loss, lower heat generation, and deliver stable, reliable charging.
Smart Cooling. Quiet by Design.
An integrated temperature sensor dynamically adjusts fan speed based on load and temperature. It delivers efficient cooling during high-power charging and quiet operation under lighter loads, helping maintain stable 65W performance.
Specs:
- Size: 84x84x45.3mm
- Weight: 200g
Power:
- AC Input：100V-240V~ 50/60Hz
- Charging Power: 65W
Batteries:
- LiPo/LiFe/Li-ion/LiHV: 2-4S
- NiMH/NiCd: 6-8S
- Pb: 3S/6S
Charge Current:
- NiMH/NiCd/LiHV/LiPo/Li-ion/LiFe: 0.1A~1A(±0.3A), 1.1A~10A(±10%)
- Pb: 0.8A~1A(±0.3A), 1.1A~10A(±10%)
Discharge Current:
- Discharge current: 0.1A ~ 2A
- Balance Current: LiHV/LiPo/Li-ion/LiFe MAX 500mA
Operation:
- LiHV/LiPo/Li-ion/LiFe: Balance CHG / Charge / Storage / Discharge
- NiMH/NiCd: Charge / Re-Peak / CYCLE_C_D / CYCLE_D_C / Discharge
- Pb: Normal/ AGM Charge/ Cold Charge/ Discharge
Working and Storage
- Operating temperature: 0℃ - 40℃
- Working humidity：5% - 75%
- Storage temperature：-10℃ - 70℃
- Storage humidity：5% - 75%
