Exceptional Power and Speed: The motor delivers high power output and supports high RPM, making it an ideal choice for high-speed applications. Optimized ESC Compatibility: Designed for seamless integration with the EzRun MAX5 HV Plus G2 ESC, enabling higher speeds and increased power output when paired. Effective Heat Dissipation: The motor features a grooved design for effective heat dissipation, reducing temperature increases and prolonging high-power, high-torque output. Durable Construction: Built with premium materials, including CNC-machined aluminum housing, top-tier bearings, ultra-thin silicon steel laminations, high-temperature-resistant oxygen-free copper wires, carbon fibre-wrapped explosion-resistant rotor, and high-strength alloy output shaft. These features ensure sustained high performance over time.
Specification:
- Scale: 1/7-1/8
- Type: Brushless, Sensorless
- Pole: 4
- KV Rating: 1600KV
- LiPo Cells: 6-12S
- No-load Current (A): 16A
- O.D.(mm): 56mm
- Length(mm): 118mm
- Shaft Diameter: 8mm
- Weight: 1270g
- Front Bearing: D22xD8xT7
- Rear Bearing: D19xD8xT6
- ESC: EZRUN MAX5 HV PLUS G2
- Vehicles: 1/8 & 1/7 and other model cars for extreme speed applications
